技術參數 Technical Parameter | |
| 型號 Model | RF-100 |
| 電壓 Voltage | AC-220V 50HZ |
| 功率 Power | 1000W |
| 熱風溫度 Heat Control | 0-300°C |
| 速度 Speed | 0.1-9m/min |
| 壓縮空氣 Pressrue | 0.35-0.5M |
| 傳動方式 Feed type | 皮帶傳動 By double belt |
| 皮帶寬度 Belt width | 20mm |
| 機器尺寸 Dimension | 1200*550*1300mm |
| 凈重 Net weight | 115kg |
RF-100特點：
1廣泛適用于無縫短褲，文胸，運動衫，泳衣，單車服等產品的貼膠
2.可編輯PLC控制，7寸觸摸屏可視化操作
3.上下皮帶可獨立調節速度，存儲10個縮率程序
4.上下皮帶，吹風，導帶槽均可獨立調節溫度，穩定定性+2度5.帶切刀修剪面料
Featuresof RF-100
1.Widely used in seamless panty,seamless bra,sports T-shirt,swimming wear,bike wear etc to press the tape
2.Controled by editable PLC with 7 inch touch screen
3.Upper and lower belts adjust the speed individually and store 10 minification programs
4.Belt,blowing and guide slot all could adjust the temperature individually with stability upto +2 degree5.Trim fabric finish with cutter
