技術參數 Technical Parameter | |
型號 Model | RF-A7 |
電壓 Voltage | AC-220V 50HZ |
功率 Power | 3200W |
壓縮空氣 | 0.35-0.5Mpa |
熱壓溫度 | Up to 250°C |
熱壓時間 | 1-999s |
熱壓面積 Max Pressing area | 380*380mm |
升降行程 Max lift height | 160mm |
機器尺寸 Dimension | 1260*650*1900mm |
凈重 Net weight | 118kg |
RF-A7特點:
1廣泛應用于無縫口袋,商標圖案等熱壓
2溫度設定準確,數字顯示只管,自動恒溫
3熱壓粘合時間由數字顯示及設定,精確無誤,作業完成后熱壓板自動上
4冷熱旋轉定位壓模設
5在熱壓工作完成后,冷壓系統可作冷卻工作,有效快速地保障面料不變色、不起皺及快速定型
6.人機界面顯示,輕觸式按鈕操作功能
7根據不同產品,熱壓粘合的壓力可自由調節
8雙工位工作面設計,提高工作效率
Features of RF-A7:
1. Widely used in seamless pocket, logo etc
2. Digital display, accurate temperature setting and auto constant temperature
3. Time of pressing is set and shown by digital and the pressing plate rises automatically after finishing work
4.Heat-cold rotatable position module design
5.Cold pressing system will work after heat pressing to finalize the design without corrugating
6.Pressing button make the operation so easy
7. The pressure of the pressing and bonding could be adjusted based on different products
8. Double working tables design improves the working efficiency
