Details
RF-A2S is special for waterproof shoes and waterproof gloves seam sealing.
技術參數 Technical Parameter | |
型號 Model | RF-A2S |
電壓 Voltage | AC-220V 50-60HZ |
功率 Power | 2500W |
熱風溫度 Heat Control | Up to 700°C |
速度 Speed | 1-24m/min |
壓縮空氣 Pressrue | 0.35-0.5M |
壓輪寬度 Roller width | 25.4mm |
上壓輪行程 Upper roller lift | 20-35mm |
機器尺寸 Dimension | 1300*600*1600mm |
凈重 Net weight | 160kg |
RF-A2S特點:
1.適用于各類防水鞋的熱風封口
2.松下PLC控制
3.上下壓輪鏈條同步傳動,自動補償虛位,自動微退,減少壓帶空白
4.雙腳踏控制,操作舒適,適宜長時間操作
5.可連續24小時工作
6.獨特發熱管結構,進風經過濾,絕無水分和油分
7.自動剪帶、送待,自動帶尾完成,減少材料損耗
8.下柱獨特超薄設計,適宜各種大小件產品密封壓帶
Featuresof RF-A2S
1.Special design for waterproof shoe seam sealing
2.Panasonice PLC control
3.The up and low roller chain are synchronous,auto compensation and reverse
4.Double pedals control
5.It could work up to 24 hours
6.Blowing -in hot air is filtrated without any water and oil
7.Auto tape clipping ,feeding and finishing reduce function
8.Supper-thin lower column design,suitable for sealing various sizes products
