技術參數 Technical Parameter | |
型號 Model | RF-A8 |
電壓 Voltage | AC-220V 50HZ |
功率 Power | 2500W |
熱風溫度 Heat Control | Up to 700°C |
速度 Speed | 1-18m/min |
壓縮空氣 Pressrue | 0.35-0.5M |
壓輪寬度 Roller width | 30mm |
適用膠帶寬度 Applied Tape Width | 14-25mm |
上壓輪行程 Upper roller lift | 20-35mm |
機器尺寸 Dimension | 1300*700*1600mm |
凈重 Net weight | 175kg |
RF-A8特點:
1.超大操作空間,臺板可拆卸,更合適大型帳篷,雨罩等產品加工
2.采用PLC可編程,觸摸式數字顯示
3.溫度自動控制,穩定性能高,溫度上限報警設計,保護發熱絲
4.自動補償虛位,自動微退,減少壓帶空白
5.雙腳踏控制,操作舒適,適宜長時間損作
6.可連續24小時工作
7.獨特發熱管結構,進風經過濾,絕無水分和油分
8.自動剪帶、送待,自動帶尾完成,減少材料損耗
Featuresof RF-A8
1.Bigger operation space and removable working table make it better for bigger tent,waterproof covers etc
2.Editable PLC control,touch screen display
3.Auto temperature control with warning device for the up limit temperature
4.Auto compensation and reverse5.Double pedals control
6.It could work up to 24 hours
7.Blowing-in hot air is filtrated without any water and oil
8.Auto tape clipping ,feeding and finishing reduce function
