技術參數Technical Parameter | |
型號 Model | RF-A13 |
電壓 Voltage | AC-220V 50HZ |
功率 Power | 2500W |
熱風溫度 Heat Control | Up to 700°C |
速度 Speed | 1-24m/min |
壓縮空氣 Pressrue | 0.35-0.5M |
壓輪寬度 Roller width | 30mm |
適用膠帶寬度 Applicable tape width | 14-25mm |
機器尺寸 Dimension | 1300*600*1550mm |
凈重 Net weight | 115kg |
RF-A13特點:
1.適用于各種防水衣物,如防水夾克,雨衣,帳篷。車罩等
2采用PLC可編程,觸摸式數字顯示
3.溫度自動控制,穩定性能高,溫度上限報警設計,保護發熱絲
4.自動補償虛位,自動微退,減少壓帶空白
5.雙腳踏控制,操作舒適,適宜長時間操作
6.可連續24小時工作
7獨特發熱管結構,進風經過濾,絕無水分和油分
8.自動剪帶、送待,自動帶尾完成,減少材料損耗
9.獨特下柱設計,更適宜桶裝型,袖口型產品的封口
Featuresof RF-A13
1.Suitable for kinds of waterproof garment and products,such aswaterproofjacket,raincoat,tent,car cover etc
2.Editable PLC control,touch screen display
3.Auto temperature control with warning device for the up limit temperature
4.Auto compensation and reverse
5.Double pedals control
6.It could work up to 24 hours
7.Blowing -in hot air is filtrated withoutany waterandoil
8.Auto tape clipping ,feeding and finishing reduce function
9.Special arm design,better for barerel sharp and cuff sharp products seamsealing
